Chopping Shear

As a professional China Chopping Shear manufacturer, we are equipped with a famous factory and plant and engineers with decades experience, as well as providing with CCM Machine, TMT Re-bar Mill, Wire Rod Mill, finishing mill, rolling mill stand, hot roling mill, section rolling mill, etc.for sale, welcome to visit and check the process and layout with Hani Metallurgy Equipment Co., Ltd.

Equipment Composittion and Use

Chopping shear is composed by motor, shear machine housing, base, pinch roll and knife rest. The chopping shear is fixed behind the track switch, and is used to chop the rolled piece cut off by the head cutting flying shear and falling into the chute of scrap collection device when some failure occurred to the rolling line.

Shearing steel type: carbon steel, low alloy steel

Shearing temperature: 850℃

Chopping shear: 260mm

Rotary diameter of blade: 250mm

Overlap amount of blade: 0.25~0.75mm

Shear blade side clearance: 0.20~0.25mm

Belt drive:

Center distance: 443.5mm        Transmission ratio 1:1        Pitch diameterΦ164mm

Gear drive:

Center distance: Φ250mm        Transmission ratio 1:1        Pitch diameterΦ250mm

Service:
- We can supply foundation layout and arrangement diagram
- After-sales service provided, we will send engineers to your factory to install and debug the machines
- Competitive price & excellent quality
- Our machines are easy operation and maintenance
- Lower investment
- Steady performance
- Products are customized for different needs
- Production capability can be adjusted according to customers' request
- Low energy consumption

As a professional Chopping Shear manufacturer in China, We can supply designing, manufacturing, installation and commissioning of the equipment with“turn-key”service. We can also design, manufacture and revamp other non-standard requirement according to the requirements of users.

Please send us more information about your project, we would like to give you our proposal immediately after getting your details. Sincerely welcome you to come and visit our plant.
